COSMO Fertilizer Spreader, P500

The COSMO Model P 500 fertilizer spreader is constructed with a lateral exit vane distribution system to ensure better spreading of seeds or fertilizer. The opening system with split levers offers the possibility to scatter fully to the right or to the left side. This manual adjustment and the speed of travel allow for granular material to be spread 39 to 46 feet and crystalline material to be spread 20 to 23 feet.

The upper parts of the heavy duty gear box are constructed of stainless steel to resist corrosion and are internally lubricated in an oil bath for a longer life. The absorbed power at 540 RPM is 6 horsepower. The transmission ratio is 1:1.

Constructed of steel and epoxy coated to resist damage and corrosion, the hopper weighs 139 pounds empty and has a 1,027 pound capacity. Capacities may vary depending on product being used. This 3-point fertilizer spreader is constructed with a sturdy steel frame that is covered with a coating system of epoxy primer and polyurethane waterborne paint. This provides excellent protection against UV rays and weathering.

The COSMO spreader has a clevis hitch to allow you to pull or drag something behind the fertilizer spreader. The seed spreader is constructed with category 1, 3-point hitch.

Specifications:
• COSMO Model P 500
• 1,027 lb capacity
• 45 inch diameter across the top of the tub
• 39 to 46 feet granular spreading width
• 20 to 23 feet crystalline spreading width
• PTO and agitator included
• Transmission ratio 1:1
• 540 RPM required
• Weight: 139 lbs.
• Manual opening system
• 3-point hitch, category 1
• Epoxy primer and polyurethane coated
• Coating protects against UV and weathering
• 2 Lateral discharge exits with galvanized shutters
• Reversible lower hitch pins
• Replacement Parts:
• ASC # 40879 Hopper
• ASC # 12276 Front gear seal
• ASC # 12259 Gearbox
• ASC # 12268 Agitator
• ASC # 12292 Lower Agitator
• ASC # 12272 Replacement vane
• ASC # 70240 Spinner and Vanes
• ASC # 12282 Seal for base of entrainer
• ASC # 31963 PTO Shaft

The COSMO fertilizer spreader, Model P500, is designed and constructed to allow the distribution of granular fertilizer and seeds in the field. The 3-point spreader has a manual adjusting gear box to allow a spreading width from 39 to 46 feet for granular material and 20 to 23 feet for crystalline material. Constructed of steel and baked with an epoxy varnish, this broadcast spreader is resistant to damage and corrosion. An agitator and PTO shaft are included.
