Agmate® Finishing Mower, 8 Ft. Rear Discharge

Measuring 96″ L x 68.25″ W x 31.5″ H, this 3pt finish mower is a rear discharge mower. This position works to eliminate grass buildup in uncut areas and reduces blade wear. This mower has a 95.67″ cut provided by 5 belt driven blades that rotate at a speed of 540 rotations per minute. The 3-point hitch is made to fit a category 1 hitch tractor, and the gearbox ratio measures 1:1.93. The finishing mower deck can be adjusted to create different cutting heights from 1.38″- 4.53″. This finishing mower is a tractor implement that can operate from 22 to 50 HP.

Specifications

• 3-Point Finishing Mower
• Gauge wheel: 3″ wide x 8″ tall, standard duty
• Gearbox HP: 45
• PTO driveline: series 4
• Dimensions: 96″ L x 68.25″ W x 31.5″ H
• Cutting width: 95.67″
• Rear discharge
• Number of blades: 5
• Deck thickness: 9.5 gauge (3.5 mm)
• Tractor hitch: Category 1
• Tractor horsepower: 22-50
• Blade Speed: 74 m/s; 2,771 RPM
• PTO turning speed: 540 rotations per minute
• Height adjustable caster wheels
• Gearbox ratio: 1:2.83
• Weight: 683 lbs.

Replacement Parts

• 83779 – Rubber Tire Assembly
• 105900 – 5/8″ X 105″ Belt (requires 2)
• 20985 – 39″ V-Belt, 21/32″ x 5/8″ FHP (requires 1)
• 105897 – Chain Rod For 8′ Agmate® Mower
• 103459 Blade for 8′ Agmate

Keep a manicured lawn by using this 3-point finish mower. At 8 feet long this mower offers a cutting width of 95.67″ (2430 mm). Perfect for landscapers, homeowners and golf course groomers alike. This finishing mower is compatible with a tractor horsepower range of 22-50.
